Installation Guide: Q-Optics™Eclipse

Step 1: Attach the bracket and headlight to frame

A) Slide Q-Optics name plate up to remove and reveal two screw posts (Picture A)
B) Slide the mounting bracket over the two screw posts (Picture B)

Step 2: Headlight Adjustment

A) Draw a circle 3" in diameter. Dim headlight to minimum.
B) While looking at the circle through the loupes, rotate and tilt the headlight to aim at the circle.
C) Use the allen wrench to tighten or loosen the headlight as needed.
